Ultraviolet Camera
PCO.ULTRAVIOLET
Based on special CCD technology the pco.ultraviolet provides highest sensitivity in the UV range of the spectrum and a dynamic range of 14 Bit. Exposure times can be adjusted from micro seconds up to one minute by software.
This ultra-compact camera system is perfectly suited for all kinds of scientific and industrial imaging applications to which UV detection is an essential requirement. |
SPECIFICATIONS
Resolution (H x V) 1392 x 1040 pixel (normal) 800 x 600 pixel (center ROI) Pixel Size (H x V) 4.65 µm x 4.65 µm Shutter Mode Global (snapshot) Spectral Range 190 nm .. 1100 nm Max. Frame Rate 7.3 / 13.5 fps (12 / 24 MHz, normal) 11.7 / 21.6 fps (12 / 24 MHz, center) Exposure/Shutter Time 1 µs .. 60 s |
Related Instruments
CCD Cameras
|
sCMOS Cameras
|
High Speed Camera
|
|
*Pictures shown above are for reference only. Actual product may differ slightly.
**Some products may not be available in all countries. Please contact us for further information and clarification. |
